ISOJAG
Removable insulation jacket tailored to ECOFLOW Venturi orifice steam traps. The Nomex and Kevlar construction uses fastening strips and pull cords for repeated removal during inspection and maintenance.
Operating limits depend on material, size and configuration. Check the pressure–temperature ratings in the relevant technical catalogue for your application.
Eco Flow · ISOJAG
Overview
Removable insulation jacket tailored to ECOFLOW Venturi orifice steam traps. The Nomex and Kevlar construction uses fastening strips and pull cords for repeated removal during inspection and maintenance.
Consider nominal size, pressure class, fluid, temperature, connection and actuation together. Refer to the technical catalogue for suitable materials and operating limits. Share the fluid, operating pressure and temperature, connection size and standard, and required control function. Include Kv/Kvs for control valves, and condensate load and back pressure for steam traps.
Technical data
| Brands | Eco Flow |
|---|---|
| Series / model | ISOJAG |
| Compatible sizes | DN15–DN50 |
| Small jacket | Part 1170; DN15–DN25; 500 × 290 mm |
| Large jacket | Part 1180; DN40–DN50; 570 × 310 mm |
| Maximum application temperature | 200°C |
| Fabric | DuPont Nomex 455 (NOMEX III); Nomex / Kevlar fibres |
| Fastening | Hook-and-loop strips; Kevlar pull cords |
Operating limits depend on material, size and configuration. Check the pressure–temperature ratings in the relevant technical catalogue for your application.
Frequently asked questions
How do I select a valve or steam trap?
Share the fluid, operating pressure and temperature, connection size and standard, and required control function. Include Kv/Kvs for control valves, and condensate load and back pressure for steam traps.
